iOptron

Photron 10 inch Ritchey-Chretien Telescope (RC10)

SKU: 6113


  • Sale
  • Regular price $2,888.00

Qualifies for Free Ground Economy Shipping (CONUS Only)


Note: This is an optical tube only designed for advanced astroimaging.

The iOptron Photron Ritchey-Chretien design telescopes, feature low thermal expansion quartz primary and secondary mirrors with ninety-nine percent reflective dielectric coatings. The RC optical design delivers coma, spherical and chromatic aberration free results, perfect for color or monochrome imaging. A fixed position primary mirror eliminates image shift that occurs from focusing with other telescope designs. The iOptron RC10 comes with a 2" dual-speed linear-bearing Crayford focuser. Three focuser extension rings are provided for a “flex-free” solid extension as a means to take up any unneeded back focus. Its steel tube is equipped with 10 knife edge baffles to diminish contrast-reducing stray light, improving the instrument in both visual and imaging uses. A RC10 model comes with top and bottom dovetail plates adding rigidity to the tube while providing attachment points for the mount and other accessories to be used.

Features
  • Coma free, chromatic aberration-free, spherical aberration-free optics
  • 250mm (10") optical aperture
  • 2000mm focal length
  • f/8 focal ratio
  • Fixed primary
  • Low thermal expansion quartz mirrors
  • Multiple Knife-Edge Baffle System
  • 3.3" Dual-dpeed Crayford focuser
  • Finder scope base and two dovetails bars
  • Optional finder scope, diagonal and 1.25" eyepiece
  • Optional iOptron Electronic Focuser (#8451)
  • OTA w/3" dual-speed Crayford focuser
  • 2X25mm, 1X 50mm focus extention
  • 1.25" accessory adapter
  • Top and bottom Losmandy dovetail bars
Optical Design Ritchey-Chretien
Clear Aperture 250mm
Focal Length 2000mm
Focal Ratio f/8
Resolving Power 0.46 arc seconds
Limiting Magnitude 14.7
Highest Useful Magnification 295X
Secondary Mirror Size 110mm in diameter
Focuser 10:1 Crayford dual-speed
Focuser size 3.3”
Dovetail Bar Losmandy-style
Mounting Bar (Top) Losmandy-style
Finderscope Base Yes
Finder scope Optional
Tube material Steel
Tube Length 28.4”
Tube Weight 35 lbs
OTA Primary Mirror Cooling Fan Yes (three built-in fan, with battery holder)
Other Accessories 2” to 1.25” compression ring adapter;
1" long extension tube X2
2" long extension tube X1
Gross Weight 48 lbs
Warranty One year limited
Barcode: 813578010629
